Product Name: led etl flat downlight
| Model No. | P023 | P023R8 | P023R15 | P023R18 | P023 |
| Size: | 3 inch | 4 inch | 6 inch | 8 inch | 12inch |
| Power | 5W | 9W | 12W | 18W | 24W |
| Dimensions | OD 90*20mm Cut out: 77 | OD 120*20mm Cut out: 105 | OD 170*20mm Cut out: 155 | OD 225*20mm Cut out: 203 | OD 300*20mm Cut out: 278 |
| Packing Info. | 54*26*47CM 50pcs/CTN G.W 19.25KG | 54*23.5*70CM 50pcs/CTN G.W 21.86KG | 39*39*32CM 20pcs/CTN G.W 10KG | 52.5*51.5*37CM 20pcs/CTN 17.3KG | 48.5*33.5*66CM 20pcs/CTN 18.5KG |
| Default Driver Input | 120V AC 60Hz (Dimmable) | ||||
| Power factor | >0.95 | ||||
| CRI | >80 | ||||
| Beam angle | 110° | ||||
| LED chips | EDISON SMD 2835 | ||||
| Available Color temperature | 2700K, 3000K, 4000K, 5000K, 6000K, 6500K | ||||
| Luminous Efficacy | 80LM/W | ||||
| Body-color | White | ||||
| Certificate | cETLus, Energy Star | ||||
| IC rated fixture and driver(Contact with insulation allowed ) | Yes | ||||
| IP grade | Damp Location | ||||
| Air tight | Yes | ||||
| Operating Temperature | Fahrenheit -40°F to +105°F Celsius -40°C to +40°C | ||||
| Driver Size | 100*70*37mm | ||||
About this item-etl flat downlight
💡Energy Saver: This ETL & Energy Star certified flat downlight only needs 13.5W to match the output of a 75W incandescent light, It also has a scratch-resistant frosted lens that prevents glare.
💡Ultra-Thin Lighting: This led flat downlight ultra-thin downlight only needs 2 inches of ceiling space, perfect for ceilings that can't fit a housing can. The metal springs clips firmly hold the light for easier install and lasting service
💡Reliable Design: The unique waterproof male and female connectors make it great for wet locations. The IC rating lets this light be in contact with insulation so you don't need to worry about it overheating and causing a fire
💡Widely Used: With smooth 100%-10% dimming and compatible with most dimmers on the market, you can easily set the mood as you like. The 110⁰ beam angle and CRI80+ let this etl flat downlight be used in garages, kitchens, and even bathrooms.
💡Trusted Quality: This etl flat downlight fits new construction, remodels, and retrofit installations. The aluminum light body extends the lifespan to 40,000hrs and the light comes backed by a 5-year warranty.
